Moor Weather

Davis VP2 Console

The Davis Vantage Pro 2 console enables the simultaneous display of many different values supplied from the Integrated Sensor Suite, additional sensor packs or from it's own internal sensors in both text and graphic formats. In addition to this it also relays information received to the Davis Weather Envoy Unit, which contains the all important data logging module.

Integrated Sensor Suite

The ISS consists of the conical black rain gauge mounted above the white louvred radiation shield, which serves to prevent temperature errors due to sunlight falling directly on the temperature sensor. This shield contains the temperature and humidity sensors but, in addition, houses the circuitry for combining the inputs from other outside sensors which are plugged into the mainboard.

Anemometer

The Anemometer measures both the wind speed and the direction and is of the standard 4-cup hemispherical design that has changed little since it was invented in the 15th century.

Made to withstand strong winds but sensitive enough to pick up even the slightest breeze. A Davis Anemometer reported wind speeds of 175mph during Hurricane Andrew before the tower it was mounted on, collapsed!

Solar Sensor

The Solar Sensort measures solar radiation and is used along with an anemometer and a temperature/humidity sensor, to monitor evapotranspiration.

The diffuser element and housing are carefully designed for accurate cosine response. Silicon photo diode provides good match to solar spectrum. Two-piece housing minimizes radiation heating, allows convection cooling of the sensor, and prevents the trapping of water or dust.

UV Sensor

The UV Sensor measures the sunburning portion of the UV spectrum. It allows the console to display UV index, dose rate, and daily and accumulated dose.

The multi-layer filter provides a spectral response that closely matches the Erythema Action Spectrum. Diffuser provides excellent cosine response. Two-piece housing minimizes radiation heating, allows convection cooling of the sensor, and prevents the trapping of water or dust.

Siting

Set on the edge of Dartmoor National Park, the ISS is mounted on a 5m alloy pole in the middle of a field with no obstructions in the vacinity. This allows for more accurate measurements and the site currently achieves a 4 star rating on the Met Office's WOW programme.

The site also reports to PWS Weather & Weatherbug.

Weather

Temperature	13.1 °C	Apparent Temperature	10.8 °C
Last Hour Variation	-0.1 °C	Wet Thermometer	9.4 °C
Average Temperature	13.1 °C	Humidity	60 %
Windchill	13.1 °C	Evapotranspiration (24h)	1.90 mm
		Cloudbase	3107 ft

Rainfall Rate	0.0 mm/hr	Rainfall Today	4.8 mm
Rainfall In The Last Hour	0.2 mm	Rainfall This Month	73.2 mm
Rainfall Since Midnight	4.8 mm	Rainfall This Year	264.8 mm
Rainfall Last 24h	4.8 mm	Last Rainfall	2019-06-16 20:42

Barometer	1000.58 hPa	Pressure Trend	0.09 hPa
Altimeter Pressure	0.00 hPa

Current Wind Speed	4.0 mph	Wind Direction	S
Wind Speed (Gust)	11.0 mph	Wind Bearing	178 °
Wind Speed (Avg)	4.0 mph	Wind Bearing (Avg)	185 °
Beaufort Scale	F2	Light breeze

Solar Radiation	0 W/m²	UV Index	0.0
Sunny?	No	Current Solar Max	0 W/m²

Sunrise	05:04	Sunset	21:30
Dawn	04:19	Dusk	22:15
Moonrise	20:37	Moonset	04:38
Day Length	16:26	Length Of Daylight	17:56
There will be 0min 27s more daylight tomorrow

Temperature:	13.1 °C
Wind Speed:	4.0 mph
Wind Direction:	S
Humidity:	60 %

24h Local Forecast

Partly cloudy with little temperature change.

Weather

Temperature

Rainfall

Pressure

Wind

Solar

Sun & Moon

Moon Phase

Summary Data

Solar
